Everyday Graphic Protection

Series 3420 is constructed of a 75 micron calendered vinyl film with clear, permanent pressure-sensitive adhesive. With one of the most consistent high-gloss levels in the industry, Series 3420 overlaminate will add outstanding clarity while providing excellent protection to your graphic. Available in Gloss, Satin, or
Matte finishes, this calendered polymeric overlaminate will be the final touch you need and provide protection to any project. Your graphic will surely stand out from the rest. Series 3420 is rated for outdoor durability up to 5 years.

Series 3420 Product Description

Protective overlaminate for all promotional, intermediate and industrial, calendered products
Short-term signage, kiosks and POP displays
Series 3420 Gloss and Matte are UL 410 approved for slip resistance for interior floor graphics
UV inhibitors to protect and extend the life of your printed graphic
Arlon overlaminate film is designed to be laminated cold without any heat

Property	Test Methods	Typical Value
Surface Finish	Gloss Meter 60° Reflection	80 to 90 Gloss Units (Gloss) 35 to 45 Gloss Units (Satin) 5 to 10 Gloss Units (Matte)
Thickness	Micrometer, Federal Bench Type	75 micron
Tensile Strength	Tensile Tester with 2-in (51 mm) jaw separation; crosshead speed of 12 in/min. (5.1 mm/s), web direction	1.8 kg/cm
Elongation	Instron Tensile Tester as above	≥ 190%
Shelf Life (In Box)	Ideal Storage Temperature 70°F (21°C) and 50% relative humidity	1 year from factory shipment
Application Temperature Range	On clean, dry substrate	4.4°C to 38°C
Service Temperature Range	Film applied to etched aluminum panels 24 hours prior to testing	-29°C to 65°C
Dimensional Stability	158°F (70°C), 48 hours	0.51 mm
Peel Adhesion	PSTC-1, 15 min, 70°F (21°C)	0.45 kg/cm
Adhesion	TLMI Release at 90˚, 300 in/min (760 cm/min)	23.62 g/cm
